B2 Audio Black 4v 10 Channel DSP with Bluetooth iOS/Android App 96 KHz - 32 Bit

$ 81.82

Type: Digital Signal Processor Model Number: B2-DSP-SIXTEN-BK MPN: B2-DSP-SIXTEN-BK UPC: 850066670804 gtin13: 850066670804 Model: SixTen Product Type: Electronic Component Digital Signal Processors Brand: B2 Audio Country of Origin: China California Prop 65 Warning: WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/. Manufacturer: B2 Audio

Description

B2 Audio Black 4v 10 Channel DSP with Bluetooth iOS/Android App 96 KHz - 32 Bit LIMITED EDITION B2 Audio Black 4v 10 Channel DSP with Bluetooth IOS/Android App 96 KHz - 32 Bit This listing includes (1) B2 Audio SIXTEN, 6 Input - 10 Output 4v DSP The B2 Audio SixTen DSP is a cutting-edge 6-input, 10-output digital signal processor designed for unmatched audio customization, now available in a limited run black finish version . With Bluetooth connectivity and an intuitive iOS/Android app, it delivers precise tuning through its 96 kHz, 32-bit resolution. Each of the 10 output channels provides a strong 4-volt signal, ensuring optimal performance for high-quality car audio setups. Technical Specifications Inputs: 6 (3 Left/3 Right) Connectors: RCA Input Level Max: 4.00 Vrms (+ 14dBu) Outputs: 10 Output Max Level: 3.50 Vrms (+ 13dBu) Frequency Response: 10Hz to 24KHz (-1dB) THD+N: <0.01% Signal Latency: <0.6 ms Bit Rate: 32-Bit Sampling Frequency: 96khz Voltage DC: 9.5 - 15v DC Maximum consumption: 350mA Processing Technical Documents Channel Routing: Routing Option: A/B/C/D/A+B/A+C/B+C Gain: General Gain: -53 to 0dB Channel Gain: -33 to +9dB Frequency Cut: Cut-Off Frequency: 20Hz - 20KHz Type of Cuts: Linkwitz-Riley / Butterworth / Bessel Attenuations: 6/12/18/24/36/48 dB/8 degrees Input Equalizer (EQ in): Equalization Band: 31 Bands Gain: -12 to +12dB Channel Equalizer (EQ Channel): Equalization bands: 8 parameter per channel Gain: -12 to +12 dB Q Factor: 0.6 - 9.9 Time Alignment (delay): Time: 0 to 18.95 ms Distance: 0 to 6500mm Limiter: Threshold: -53 to +6dB Attack: 1 to 200ms Release: 1 to 988ms Polarity Inversion (Polarity): Inversion: 0 or 180 Degrees Memory (Preset): Memories: 3-100% Configurable Product Dimensions: Length: 4.5" Width: 5.75" Height: 1.5" Weight: 13.6 oz Download the app from the QR Codes in the owners manual or from the download links on the manufacturer website. The default password for the DSP is 000000 - to set a new password, just enter any password other than 000000. If you forget your own password, press and hold the reset button for 15 seconds to reset the device to factory settings. (This will also reset all of your settings saved in the app.) Product Details Brand B2 Audio Color Black Manufacturer B2 Audio Mpn B2-DSP-SIXTEN-BK Advanced Digital Signal Processing – 6-input, 10-output DSP with 96 kHz, 32-bit resolution for crystal-clear audio and precise tuning. Wireless Control via Bluetooth – Adjust settings effortlessly using the iOS & Android app, offering real-time customization from your smartphone. High-Voltage Output for Optimal Performance – Each of the 10 output channels delivers a 4-volt signal, ensuring maximum clarity and power for your audio system. Compact and Durable Design – Engineered for seamless integration into any setup with a space-saving 4.5” x 5.75” x 1.5” form factor. Professional-Grade Sound Quality – Designed for audiophiles and car audio enthusiasts seeking precise frequency control, low distortion, and superior sound staging. - Powered by

  1. I’m not gonna bad mouth anyone because they heard what I had to say and assured me that it would be corrected in the near future, yes I would order from this company anytime and I’m very grateful that they handle my issue with out run around! Very professional!!! Thank you again!! God Bless!!

    Gyanendra Giri

  2. Well done B2! I have installed the dsp, as it arrived quickly and I'm using all 10 output channels. I am very pleased with its functionality to cost ratio! This dsp even though it is modestly priced can hold its own with the more expensive units on the market.

    Junf7ba29d01

  3. Awesome seller!!! Great build quality, excellent condition, super value, sleek design… Considering purchasing another just to have on standby for any other projects.

    siva03c7326c
